IC-8® Apthera™ IOL
Small Aperture Extended Depth of Focus IOLs
IC-8® Apthera™ is a small-aperture presbyopia-correcting IOL designed to extend depth of focus through wavefront-filtering technology.1
The IC-8® Apthera™ IOL uses small-aperture, wavefront-filtering technology to extend depth of focus from near to far.1
Harness the Power of Focused Light
By filtering out defocused light rays, the IC-8® Apthera™ IOL helps many patients achieve a broader range of vision—from near to far—while maintaining continuous visual clarity.
Broadens Visual Range →
Extended Depth of Focus →
Vision for Everyday Activities →
Clear Range of Vision
Continuous and free from
“blurry zones” near to far
Designed to Perform
Delivering only high-quality
light to the retina
Everyday Vision
Monofocal-like distance with enhanced
intermediate and near vision
Extending Range, Brilliantly
Small-aperture optics support extended depth of focus while addressing everyday visual demands.1
Expanded Vision with Reliable Outcomes
The IC-8® Apthera™ IOL helps broaden visual range across multiple distances, manages mild astigmatism effectively, and promotes reliable outcomes for your patients and practice.
- Enhance Surgical Outcomes: Designed to deliver clear vision across multiple distances—near, intermediate, and far.
- Achieve Excellent Patient Satisfaction: Reduce “blurry zones” so patients can enjoy everyday activities with greater freedom and fewer visual distractions.
- Versatile Performance: Excellent results in eyes with up to 1.5 D of corneal astigmatism.
- Optimized Clarity: Patients benefit from sharp images and monofocal-like binocular contrast sensitivity in bright and low light conditions.
Simulated Visual Contrast from US Air Force Target Imaging
Simulated target imaging provides a visual comparison of image contrast across different IOL optic designs.
US Air Force target imaging illustrates simulated visual contrast with IC-8® Apthera™ alongside a monofocal IOL, diffractive EDOF IOL, and trifocal IOL.1,3
Monofocal IOL TECNIS®, Diffractive EDOF IOL Symfony®, Trifocal IOL AT LISA®.
Intuitive Integration
IC-8® Apthera™ is designed to fit familiar cataract surgery workflows with a monofocal-like procedure and minimal intraoperative learning curve.1
The small-aperture design also provides an option for eyes with up to 1.5 D of corneal astigmatism without toric axis alignment.1,3
Keratometry data from 6,000 eyes showed that 82% of cataract patients had 1.5 D or less of corneal astigmatism.2
Built for a Common Cataract Patient Profile
82% of cataract patients present with 1.5 D of corneal astigmatism or less.
Enhancing Vision From Near to Far
A small central aperture filters unfocused light to extend depth of focus across multiple distances.1
Precision Technology for Extended Depth of Focus
At the center of IC-8® Apthera™ is a small-aperture optic designed to filter defocused light and extend visual range from near to far.1
Wavefront-filtering technology directs higher-quality light to the retina while preserving a familiar monofocal platform.1
Central Aperture Design
The IC-8® Apthera™ IOL uses a 1.36 mm central aperture to filter peripheral defocused light and extend depth of focus.1
- Precise Light Control: The Apthera™ IOL wavefront-filtering technology focuses only higher-quality light to the retina while filtering out unfocused, low-quality light.
- Small Aperture Technology: Continuously extended depth of focus for a seamless range of vision near to far.
The 1.36 mm central aperture directs higher-quality central light to the retina while filtering unfocused peripheral light.1
IC-8® Apthera™ incorporates a 3.23 mm Carbon Black FilterRing™ with a 1.36 mm central aperture.1
Carbon Black FilterRing™
- Hydrophobic Acrylic Platform: Trusted in cataract surgery for its biocompatibility and clarity.
- UV-Blocking and Glare Reduction: Carbon Black FilterRing™ incorporates recognized standards for patient ocular safety.
Built on a Trusted Monofocal Platform
- Surgical Familiarity: The IC-8® Apthera™ IOL uses a high-quality monofocal platform, so surgeons can expect the handling and implantation ease they already know while addressing presbyopia.
- Reliable Materials: Hydrophobic acrylic and UV-blocking construction offer durability and safety.
IC-8® Apthera™ is built on a high-quality aspheric monofocal platform that supports its small-aperture optical design.1
Monofocal-like Distance Vision
A monocular small-aperture strategy designed to support binocular distance, intermediate, and near vision.1
Vision for Everyday Activities
The IC-8® Apthera™ IOL is implanted monocularly, with your preferred monofocal or monofocal toric IOL in the other eye.
With a small amount of near correction (-0.75 D) in the IC-8® Apthera™ IOL eye and emmetropia in the fellow eye, patients can achieve monofocal-like distance vision, while providing enhanced visual acuity through intermediate and near for everyday activities.
Additionally, this intentional combination delivers binocular monofocal-like contrast sensitivity in bright and low light conditions.
See Across a Full Range of Vision, Without Blur
With approximately -0.75 D of near correction in the IC-8® Apthera™ eye and emmetropia in the fellow eye, the intended binocular strategy supports monofocal-like distance vision with enhanced intermediate and near visual acuity.1
This binocular approach is designed to provide monofocal-like contrast sensitivity in bright and low-light conditions.1
IC-8® Apthera® is designed to support a continuous visual range from near to far through small-aperture wavefront filtering.1
With the addition of a small amount of myopia, the Apthera™ IOL improves intermediate and near vision without significantly compromising distance vision1.
When implanted contralaterally with a monofocal IOL in the fellow eye, Apthera™ IOL patients maintain better than 20/32 across 2.21 D of binocular distance-corrected depth of focus1
References:
- IC-8® Apthera™ IOL Directions for Use.
- Warren Hill, MD, Keratometry Databases, n=6,000.
- Data on file.
| Model | IC-8® Apthera™ IOL |
| Material (Optic and Haptic) | Hydrophobic Acrylic UV-blocking |
| Powers | +10.0 D through +30.0 D in 0.5 D increments |
| Optic Type | One-piece Biconvex, anterior aspheric surface |
| Optic Diameter (ØB) | 6.0 mm |
| Overall Diameter (ØT) | 12.5 mm |
| Optic Edge Design | 360° posterior square edge |
| Haptic Design | Modified C-loop haptic with 5° angulation |
| Refractive Index | 1.483 at 35°C and 589 nm |
| Filterring™ Component Material | Polyvinylidene fluoride (PVDF) with carbon black |
| Filterring Component Outer Diameter | 3.23 mm |
| Filterring Component Inner Diameter (Aperture) | 1.36 mm |
| Biometry | Optical |
| A-Constant | 120.5 |
| Surgeon Factor | 2.64 |
| Anterior Chamber Depth (ACD) | 6.42 |
Frequently Asked Questions About IC-8® Apthera™ IOL
1. What is the IC-8® Apthera™ IOL?
IC-8® Apthera™ is a small-aperture presbyopia-correcting intraocular lens designed to provide extended depth of focus through wavefront-filtering technology.1
2. How does the IC-8® Apthera™ small-aperture IOL work?
IC-8® Apthera™ uses a small central aperture to filter defocused light and direct higher-quality light to the retina, helping extend depth of focus from near to far.1
3. Is IC-8® Apthera™ an EDOF IOL?
Yes. IC-8® Apthera™ is a small-aperture extended depth of focus IOL designed to broaden visual range across near, intermediate, and distance vision.1
4. What is wavefront-filtering technology in the IC-8® Apthera™ IOL?
Wavefront-filtering technology filters unfocused, lower-quality light while allowing higher-quality central light to reach the retina. This design supports continuous extended depth of focus.1
5. What range of vision does IC-8® Apthera™ provide?
IC-8® Apthera™ is designed to provide a continuous range of vision from near to far, with monofocal-like distance vision and enhanced intermediate and near vision.1
6. Does IC-8® Apthera™ create separate focal zones?
The small-aperture design is intended to provide continuous extended depth of focus rather than discrete zones of vision, helping reduce “blurry zones” across the visual range.1
7. What is the central aperture size of the IC-8® Apthera™ IOL?
The IC-8® Apthera™ IOL has a 1.36 mm central aperture within a 3.23 mm FilterRing™.1
8. What is the Carbon Black FilterRing™ in IC-8® Apthera™?
The Carbon Black FilterRing™ is a 3.23 mm component surrounding the 1.36 mm central aperture. It is made of polyvinylidene fluoride with carbon black and is incorporated into the hydrophobic acrylic IOL platform.1
9. Is IC-8® Apthera™ implanted in both eyes?
IC-8® Apthera™ is intended for monocular implantation, with a preferred monofocal or monofocal toric IOL implanted in the fellow eye.¹
10. What refractive target is used with IC-8® Apthera™?
The recommended binocular strategy uses a small amount of near correction, approximately -0.75 D, in the IC-8® Apthera™ eye with emmetropia targeted in the fellow eye.1
11. What visual benefit does the monocular IC-8® Apthera™ strategy provide?
With approximately -0.75 D in the IC-8® Apthera™ eye and emmetropia in the fellow eye, the intended binocular strategy provides monofocal-like distance vision with enhanced intermediate and near visual acuity.¹
12. How does IC-8® Apthera™ perform in patients with corneal astigmatism?
IC-8® Apthera™ has demonstrated reliable results in eyes with no corneal astigmatism through 1.5 D of corneal astigmatism.1,3
13. Does IC-8® Apthera™ require toric axis alignment?
For eyes with up to 1.5 D of corneal astigmatism, IC-8® Apthera™ does not require the toric axis-alignment process associated with toric IOL implantation.1,3
14. How common is 1.5 D or less of corneal astigmatism in cataract patients?
According to the Warren Hill keratometry database of 6,000 eyes, 82% of cataract patients presented with 1.5 D of corneal astigmatism or less.²
15. How does IC-8® Apthera™ affect contrast sensitivity?
The intended binocular implantation strategy is designed to provide monofocal-like contrast sensitivity in bright and low-light conditions.1
16. Is IC-8® Apthera™ built on a monofocal IOL platform?
Yes. IC-8® Apthera™ is built on a high-quality aspheric monofocal platform using hydrophobic acrylic material and a familiar one-piece IOL design.1
17. What are the dimensions of the IC-8® Apthera™ IOL?
IC-8® Apthera™ has a 6.0 mm optic diameter and a 12.5 mm overall diameter, with modified C-loop haptics and 5° angulation.1
18. What power range is available for IC-8® Apthera™?
IC-8® Apthera™ is available from +10.0 D through +30.0 D in 0.5 D increments.1
19. What material is used in the IC-8® Apthera™ IOL?
IC-8® Apthera™ uses a hydrophobic acrylic, UV-blocking optic and haptic material. The FilterRing™ component is made of PVDF with carbon black.1
20. Which cataract patients may be appropriate for IC-8® Apthera™?
IC-8® Apthera™ may be considered for appropriate cataract patients seeking a presbyopia-correcting IOL with extended depth of focus, including patients with up to 1.5 D of corneal astigmatism. Final IOL selection should be based on ocular health, refractive goals, and surgeon judgment.1,3
References:
1. IC-8® Apthera™ IOL Directions for Use.
2. Warren Hill, MD, Keratometry Databases, n=6,000.
3. Data on file.
-
