enVista®
Family of IOLs
The Bausch + Lomb legacy of innovation, quality and craftsmanship is easy to see in the unique properties of the enVista® IOL which delivers exceptional rotational stability and high quality vision for a broad range of patients.
Aberration Free Optic
With its advanced aberration-free optic, the enVista® family of IOLs provide a desirable compromise between depth of field and image quality.
*Bench study of focus images under mesopic conditions using a model cornea with spherical aberration of 0.27 μm over 6.0mm.
1. Packer M. enVista hydrophobic acrylic intraocular lens: glistening free. Expert Review of Ophthalmology. 2015; 10:5,415-420
Distinctive Lens Design
The distinctive design of the enVista® family of IOLs ensures stable performance, predictability and visual clarity.
TruSight™ Optic: Glistening-free material with potential for increased scratch resistance
- Advanced material 25x harder than traditional hydrophobic acrylic lenses helps promote increased resistance to scratches and abrasions2
- enVista has proven, glistening-free performance6
StableFlex™ technology: Controlled and efficient unfolding
- Provides improved material properties to enhance optic recovery3*
SureEdge™ design: 360-degree posterior square edge
- In the clinical study, there was a low incidence of PCO5
- A continuous, 360-degree posterior square edge potentially prevents PCO compared to round edge designs4
- Micro-grooved peripheral edge to help reduce edge glare5
AccuSet Haptics: Stable Performance
- Unique haptic fenestrations facilitate intraoperative lens manipulation
*Compared to the previous generation MX60
2. Elachchabi A, Martin P, Goldberg E, Mentak K. Nanoindentation studies on hydrophobic acrylic IOLs to evaluate surface mechanical properties. Paper presented at: XXV Congress of the European Society of Cataract and Refractive Surgeons (ESCRS); September 8-12, 2007; Stockholm, Sweden.
3. Data on file.
4. Buehl W, Findl O. Effect of intraocular lens design on posterior capsule opacification. J Cataract Refract Surg. 2008;34:1976-1985
5. Data on file.
6. enVista directions for use.
SimplifEYE™ IOL Delivery System
The benefits of enVista® are now preloaded
- SimplifEYE's preloaded cartridge helps to ensure proper positioning and helps reduce risks associated with handling
- Streamlined loading and intuitive operation for procedural efficiency
SimplifEYE's three easy steps are designed to help accelerate procedures:
Monofocal | ||
---|---|---|
Model number | MX60E | MX60PL |
SKUs for ordering in US | MXUE (+Spherical Power) |
MXUEPL (+Spherical Power) |
Injectors (2.4mm incision size) | ||
BLIS injector system | x | |
INJ100 | x | |
SimplifEYE delivery system | x | |
Diopter range | 0 to +10D in 1.0D increments +10D to +30D in 0.5D increments +30D to +34D in 1.0D increments |
|
Optic size | 6 mm | |
Optic length | 12.5 mm | |
Haptics | Modified C, fenestrated | |
Optic design | Aspheric Aberration-free Biconvex |
|
Other features | Glistening free-hydrophobic acrylic material Refractive index: 1.53 at 35° UV absorbing Sharp 360° square posterior edge |
|
Optical biometry | Optical A-constant*: 119.1 ACD: 5.61 mm Surgeon Factor: 1.85 mm |
|
Applanation biometry | Applanation A-constant*: 118.7 ACD: 5.37 mm Surgeon Factor: 1.62 mm |
*A-constant values are suggested as a guideline. Physicians should calculate lens power based on optimization of their experience and preference with IOL technology.
Toric | ||
---|---|---|
Model Number | MX60ET | MX60PT |
SKUs for ordering in US | MXUET (+Cylinder +Spherical Power) |
MXUPT (+Cylinder +Spherical Power) |
Injectors (2.4mm incision size) | ||
BLIS injector system | x | |
INJ100 | x | |
SimplifEYE delivery system | x | |
Diopter range | +6D to +30D in 0.5D increments | |
Optic size | 6 mm | |
Optic length | 12.5 mm | |
Haptics | Modified C, fenestrated | |
Optic design | Aspheric Aberration-free Biconvex (posterior toricity for MX60ET & MX60PT) |
|
Other features | Glistening free-hydrophobic acrylic material Refractive index: 1.53 at 35° UV absorbing Sharp 360° square posterior edge |
|
Optical biometry | Optical A-constant*: 119.1 ACD: 5.61 mm Surgeon Factor: 1.85 mm |
|
Applanation biometry | Applanation A-constant*: 118.7 ACD: 5.37 mm Surgeon Factor: 1.62 mm |
*A-constant values are suggested as a guideline. Physicians should calculate lens power based on optimization of their experience and preference with IOL technology.
Cylinder Power | |||||||
---|---|---|---|---|---|---|---|
IOL plane | 1.25 | 2.00 | 2.75 | 3.5 | 4.25 | 5.00 | 5.75 |
Corneal plane | 0.90 | 1.40 | 1.93 | 2.45 | 2.98 | 3.50 | 4.03 |
Range of predicted postoperative corneal cylinder | 0.77 - 1.39 | 1.40 - 1.92 | 1.93 - 2.44 | 2.45 - 2.97 | 2.98 - 3.49 | 3.50 - 4.02 | 4.03 - 4.53 |
